Description
Connection Tightening Method – Wrench
Freight Class – 70
Gauge Diameter – 2.00000
HTS Classification Number – 8481100090
Industry Type – Fabrication|Welding
Inlet CGA Number – 510
Inlet Connection Gender – Male
Inlet Connection Location – Side Port
Inlet Connection Size – .880
Inlet Pipe Size – 0.8800
Inlet Pressure Cylinder ~ Max – 350
Inlet Pressure Gauge Max – 500
Inlet Pressure ~ Max – 350
Inlet Thread Standard – NGO
Inlet Threads Per Inch – 14.00
Item Depth US – 1.3000
Item Width US – 9.0000
Outlet CGA Number – 023
Outlet Connection Gender – Male
Outlet Connection Size Description – 9/16″
Outlet Fitting Type – B Size
Outlet Pipe Size – 0.5625
Outlet Pressure Gauge Max – 15
Outlet Pressure ~ Max – 15.00
Outlet Pressure ~ Min – 0.00
Outlet Thread Direction – Left Hand
Outlet Thread Standard – UNF
Outlet Threads Per Inch – 18.00
Packaged Height Metric – 144.7800
Packaged Length Metric – 190.5000
Packaged Weight Metric – 1.6103
Packaged Width Metric – 185.4200
Regulator Adjustment Type – Plastic Knob
Regulator Application – Welding|Cutting
Regulator Body Material – Brass
Regulator Bonnet Material – High Strength Alloy
Regulator Capacity – High Capacity
Regulator Gas Service – Acetylene|C2H2
Regulator Gauge Type – Dual
Regulator Housing Cap Material – Zinc Aluminum
Regulator Model – G350-15-510
Regulator Mount Type – Cylinder Mount
Regulator Relief Valve Type – Internal
Regulator Series – G 350
Regulator Side CGA Number – 510
Regulator Side Thread Direction – Left Hand
Regulator Side Thread Form Type – NGO
Regulator Stage – Single
Regulator Type – Industrial
Features
Forged brass body and zinc aluminum housing cap
Larger regulator body for heavy duty applications
Easy to read high contrast gauges for clarity
Scale and red tick mark to indicate actual service pressure
Color coded knobs indicate gas type
Designed for better comfort when adjusting gas pressure
High strength alloy bonnet with nearly twice the yield strength of brass
