Description
Connection Tightening Method – Wrench
Diaphragm Material – Neoprene
Freight Class – 70
Gauge Diameter – 2.00000
Industry Type – Industrial|Fabrication|Maintenance and Repair
Inlet CGA Number – 540
Inlet Connection Gender – Female
Inlet Connection Location – Side Port
Inlet Connection Size – .908
Inlet Pressure Cylinder ~ Max – 3000
Inlet Pressure Gauge Max – 4000
Inlet Pressure ~ Max – 3000
Inlet Thread Standard – NGO
Inlet Threads Per Inch – 14.00
Outlet CGA Number – 022
Outlet Connection Gender – Male
Outlet Connection Size Description – 9/16″
Outlet Fitting Type – B Size
Outlet Pipe Size – 0.5625
Outlet Pressure Gauge Max – 200
Outlet Pressure ~ Max – 125.00
Outlet Pressure ~ Min – 5.00
Outlet Thread Direction – Right Hand
Outlet Thread Standard – UNF
Outlet Threads Per Inch – 18.00
Packaged Height Metric – 114.3000
Packaged Length Metric – 203.2000
Packaged Weight Metric – 1.3608
Packaged Width Metric – 228.6000
Regulator Adjustment Type – T-Handle
Regulator Application – Welding|Cutting,Heating
Regulator Body Material – Brass
Regulator Bonnet Material – Brass
Regulator Capacity – Medium Capacity
Regulator Gas Service – Oxygen
Regulator Gauge Type – Dual
Regulator Housing Cap Material – Brass
Regulator Model – RC250-125-540
Regulator Mount Type – Cylinder Mount
Regulator Relief Valve Type – Internal
Regulator Series – RC 250
Regulator Side CGA Number – 540
Regulator Side Thread Direction – Right Hand
Regulator Side Thread Form Type – NGO
Regulator Stage – Single
Regulator Type – Industrial
Standard Pack Units – 1.0
Standard Pack UOM – EA
Standard UOM – EA
Features – Durable brass body and bonnet
Stem type seat mechanism – Neoprene diaphragm
Internal relief – Single stage design
